This kit is not a software product and it does not do anything on its own..  It is a library of Object Styles and MvBlocks designed exclusively for Autodesk^®'s AutoCAD Architecture 2017 and up CAD program.

This product was designed to update, improve and expand upon the stock furniture content that comes with AutoCAD Architecture.  It has evolved to include solutions for Bars, Restaurants and Office Cubicles.  All content has Material assignments for high quality rendering work. The majority of Objects in this product are based on Mass Elements but we have also added many Objects that are based on Curtain Walls to allow for individualized control.  All of the new G3 Cabinets, for example, can be Stretched and/or Height Adjusted to fit your design needs.

New for FURNITURE 21.0: Sports Tool Palette with Gym Equipment, Basketball Stand, Hoop and Backboard.  Industrial Tool Palette with freestanding and built-in tool boxes for garages.  New outdoor furniture and a Fabrics Tool Palette with high-quality fabric-like items (such as pillows).

This product has been designed to work entirely within AutoCAD Architecture's Content Browser.  Each product comes as a Catalog within which you will find Tool Palettes and Tool Catalogs organizing the various components found within the product.

Below is a list of the MvBlocks and Object Styles that you will find in this kit.

All ePart Objects have been optimized for work using the AutoCAD Architecture 2017 (and up) "Aec model (imperal - ctb).dwt" and "Aec model (imperal - stb).dwt" default template files.

Illustrated to the right is an example of how the three primary Display Representations, Low, Medium and High Detail, affect ePart Objects.  Most ePart Objects include an AecPolygon Style set to Mask background information.  This mask can be turned off if desired.

Low Detail
The Low Detail Display Representation will affect the Plan and Model Display Representations.  In Plan View linework has been simplified to a little as possible while conveying the basic information of the Object.  In Model View this Detail Display Representation will show Objects in Colors you specify by direct assignment or by Layer; i.e., the Objects are set to "ByBlock".

Medium Detail
The Medium Detail Display Representation will affect the Plan and Model Display Representations.  In Plan View you will see either see the same amount of detail as under Low Detail or High Detail depending on what we considered the better choice.  In Model View Colors are determined by the Material assignment and do not use image maps.

High Detail
The High Detail Display Representation will also affect the Plan and Model Display Representations.  In Plan View all linework is displayed..  In Model View Objects will display Materials by their image map assignment ready for Rendering.
